Climate Control Unit - CCU
Technical Specifications
General
Safety EN 60 950 class I
UL 60 950
CE
EMI, radiated EN 55022, class B
Compliant with EN 300 386-2
FCC part 15
Telcordia GR-1089
Cooling Convection cooled
Protection IP20
Input
Voltage range 18 … 59 V
DC
Current maximum 0.4 A
DC
maximum
EMI, conducted EN 55022, class B
Input protection Internal fuse
Input switch None
Features
Cooling control Up to 2 ports
Heater control 1 port
Lighting control 1 port
Temperature 2 ports
Intrusion 1 port
Display LED
Local monitoring 7-segment LED
Remote monitoring None
Remote alarming Dry contacts
Function
Outdoor cabinet environment control
Versatile cooling devices control
Heater control
Lighting control
Local parameter setting function w/o additional tool
AC or DC type cooler, heater and lighting compatible
PWM fan speed control
User definable alarm
o C / o F convertible display
User Interfaces
Status indications LED Cooling 1
LED Cooling 2
LED Heater
LED CCU Fail
LED Alarm
3-digit 7-segment LED:
Environment temperature,
parameter setting, error
messages
Dry Contact 1. Major
2. Minor
3. Alarm
4. Aux-Alarm
5. System Major Alarm
6. System Minor Alarm
Alarm
LED CCU Fail
Alarm
7-segment LED Cooling 1 fail
Cooling 2 fail
Heater fail
High temperature
Low temperature
Temperature sensor fail
Intrusion alarm
High water
Smoke / Fire
High humidity
Mechanics
Height, body 95 mm / 3.7 in
Height, overall 115 mm / 4.4 in
Width, overall 120 mm / 4.7 in
Depth, body 55.8 mm / 2.2 in
Depth, overall 60.1 mm / 2.4 in
Weight 0.24 kg / 0.5 lb
Environment
Operating temperature -40 … +70 °C /
-40 … +158 °F
Relative humidity 95 %, non condensing
All specifications are subject to change without notice
according to engineering progress.
