Elenco 3 1/2 Digit with Temperature User Manual
Page 5
2. Safety Symbols
Symbols used on the meter and in this manual are explained in
Table 2.
Table 2. International Electrical and Relative Symbols
3. Front Plate of Meter
Figure 1. Front plate of the meter
-5-
~
AC (Alternating Current)
Important Information
~
DC and AC
Caution, risk of electric shock
DC (Direct Current)
Earth Ground
Equipment Safety Standard
Low Battery Indicator
Double Insulated
!
+
LCD Display
Function Press
Button
Function
Rotary Switch
Input Terminal
