Elenco 3 1/2 Digit with Temperature User Manual
Page 2
Contents
1. Safety Information
3,4
2. Safety Symbols
5
3. Front Plate of the Meter
5
Input Terminal
6
Function Rotary Switch
7
Function Press Button
8,9
LCD Display
10
4. Power On Option
11
5. Auto Power Off
11
6. Measurement Range
11
7. Making Measurements
12
Preparation
12
Measuring Voltage
12
Measuring DC Voltage
13
Measuring AC Voltage
14,15
Measuring Current
16
Measuring DC Current
17-19
Measuring AC Current
19-21
Measuring Resistance
21,22
Testing Diodes
23
Testing for Continuity
24
Measuring for Capacitance
25,26
Measuring Frequency
27
Measuring Duty Cycle
28,29
Measuring Temperature
29,30
8. Maintenance
31
Battery Replacement
31
Fuse Replacement
32
9. General Specifications
33-35
-2-
