Elenco 3 1/2 Digit with Temperature - Manual (Page 35)

Table 12. Capacitance Detailed Accuracy Specifications
Table 13. Diode Detailed Accuracy Specifications
Overload protection: 250V rms
Table 14. Frequency & Duty Cycle Detailed Accuracy Specifications
Table 15. Temperature Detailed Accuracy Specifications
-35-
Range Resolution Accuracy Note
40nF 10pF ±(3.5% rdg + 10)
Overload Protect: 250V rms
400nF 100pF
±(3.0% rdg + 5) 4
µF
1nF
40
µF
10nF
100
µF
100nF ±(3.5% rdg + 5)
Range Description Note
Display reads approximate
forward voltage of diode Forward DC current approx. 1.5mA;
Reversed DC voltage approx. 1.5V.
Range Resolution Accuracy Sensitivity Note
5.12Hz
-
10MHz
0.001Hz
-
10kHz
±(0.1% rdg + 5)
<1MHz:
0.7V rms;
>1MHz:
1.5V rms
Overload
Protect:
250V rms
Duty Cycle:
10Hz-1kHz
0.1% - 99.9% 0.1% ±(2.5% rdg + 5) 1.5V rms
Range Accuracy Note
–58 O F - 752 O F
±0.75% ±5 O F
5 O F (room temperature)
±1.5% ±5 O F
