Reinstall air filter housing along with supplied high-flow air filter, followed by air box inlet and
tighten the two T20 torx screws.
n
Next, remove fan assembly first by disconnecting the fan connector. Next unclip the two radiator
hose clamps (they unclip from below), followed by removing two 10mm bolts that hold the fan
assembly on. Remove fan assembly by moving it up and out away from the radiator.
