6. Bias adjustment
Suspend bias adjustment weight on
scale bar at rear of main arm.
Position should correspond exactly
with tracking force setting.
Each pitch coincides with 0.5grs of
tracking force (see Fig 8)
In some case due to record material
or stylus shape of cartridge, you
could obtain the better result to
readjust the weight.
All adjustments and setting up are now completed. Your DV501 arm is designed to be maintenance
free. It will give long and reliable service but should be treated with care and kept in a dust free
condition.
Should the arm require an overhaul or if you need any quations or spare parts for your DV501 please
contact your dealer or Dvnavector distributor.
6. Specifications
System Bi-axls inertia controlled dynamic and eddy current damping
static balance type tone arm
Total length 309mm (including headshell)
Effective length 241mm
Overhang 15mm
Offset angle 21.5 degree
Height 54mm (liftable up to 94mm )
Depth 55mm (without connecting cable )
Height adjustability 36-76mm (at sub arm center)
Optimum cartridge weight 15 - 30 grms ( including headshell)
Tracklng force adjustability 0 - 3 grams by 0.5 grams step
Lateral tracking angle error -1.1 degree to +2.2 degree
(0 degree at inner band of record disk, 2.2 degree at outside)
Motion sensitivity Lateral -- less than 50 mgrams
Vertical -- less than 20 mgrams
Net weight 960 grams
Output connector 5P connector with low resistance cord 0.025 ohms/m, 50pF/m
Head connector: EIA standards
Head shell Aluminum diced and milled (weight 15 grams)
