Q-See QT528 - Manual (Page 35)

34
User name User name of broad band account
Password Password of broad band account
DDNS server
DDNS
server
Website provided by dynamic domain name supplier.
The optional: myq-see.com, www.dyndns.com
User name User name to log in to the website of domain name
supplier
Password Password to log in to the website of domain name
supplier
4.6.2 Sub Stream
Step 1: Enter into system configuration
network configurationsub stream; refer to Fig 4-33:
Fig 4-33 Network Configuration-Sub Stream
Step 2: Select fps, resolution, quality, encode and max bit rate
Step 3: User can setup all channels with same parameters, checkmark “all”, then to do relevant setup.
Step 4: Click “default” button to restore default setting; click “apply” button to save the setting; click “exit” button to
exit current interface.
4. Definitions and descriptions of network stream:
5.
Parameter Meaning
FPS Range from: 1-30
Resolution Supports CIF and D1
Quality The quality of the video image. The higher the value is, the clearer
the recorded image, and the more hard drive space the recordings
take up. Six options: lowest, lower, low, medium, higher and highest.
Encode VBR and CBR
Max bit rate Range from: 64 Kbps, 128 Kbps, 256 Kbps, 512 Kbps, 768 Kbps,
1Mbps, 2 Mbps
4.6.3 Email
Step1: enter into system configuration network configurationemail; refer to Fig 4-30:
