E.D. BULLARD COMPANY
• PRODUCT EVALUATION REPORT •
PRODUCT EVALUATION REPORT NUMBER: PER 5523
DATE: October 3, 2012
TO: Landon Borders
CC: Wayne Ruggles, Lincoln Dreher, Adam Halbert, Matt Elmore
Product Evaluation Report Files
PRODUCT EVALUATED: Eclipse powerhouse with EclipseLD
REQUESTED BY: Landon Borders
EVALUATED BY: Jeff Himes
PURPOSE OF EVALUATION: Testing for Belgium Tender.
SPECIMENS: One Truckmount assembly and Eclipse camera was provided by Landon
Borders.
METHOD: Weight the camera, and then install the camera into the truck mount. Applied
10X the cameras weight (10G’s) to the approximate center of gravity (CG) of the camera in
each direction (front, back, left side, right side). A Chatillon Force gauge (ID# 117-017) was
used to apply a pull force to the camera sample. The camera was observed to see if it had
disengaged/dislodged or maintained in the truck mount.
RESULTS: The weight of the Eclipse camera sample was 1.95 lbf. The corresponding force
associated with propelling this camera under an acceleration of 10G is 19.5 lbf.
Direction of pull Force applied (lbf) Pass/Fail
Front >20 Pass
Back >20 Pass
Rightside >20 Pass
Leftside >20 Pass
Top 14 Fail
I certify the above evaluation was conducted in accordance with standard methods.
WA Ruggles
-------------------------------------
Wayne Ruggles
Laboratory Manager
