ESM-CDV User ’s Manual
ESM-CDV User ’s Manual 57
1.5 GB
1.75 GB
2 GB
2.25 GB
2.5 GB
2.75 GB
3 GB
3.25 GB
largest MMIO length of installed
graphic controller.
3.6.3.1.2 Intel IGD Configuration
Item Option Description
VBIOS Version
1071 eDP-LVDS[Default]
1085 eDP-LVDS
EMGD (A813)
Select the VBIOS version
IGFX - Boot Type
VBIOS Default[Default]
CRT,
CRT+LVDS,
LVDS,
LVDS+CRT,
Select the Video Device which will
be activated during POST. This
has no effect if external graphics
present.
Panel Scaling
Auto[Default]
Force Scaling
Off
Maintain Aspect Ratio
Select the LCD panel scaling
option used by the Internal
Graphics Device.
Active LFP
No LVDS
Int-LVDS (eDP-7511) [Default]
Select the Active LFP
Configuration.
No LVDS: VBIOS does not enable
LVDS.
Int-LVDS: VBIOS enables LVDS
driver by integrated encoder.
SDVO LVDS: VBIOS enables
LVDS driver by SDVO encoder.
eDP Port-A: LFP Driven by
Int-DisplayPort encoder from
