User’s Manual
EBM-BYT User’s Manual 17
JBKL1 LCD Inverter connector 5 x 1 wafer, pitch 2.00mm
JBKL2 LCD Inverter connector 2 x 1 wafer, pitch 2.00mm
COM1 Serial Port 1 connector D-sub 9 pin, male
COM2 Serial Port 2 connector 5 x 2 wafer, pitch 2.00mm
JCOM3 Serial Port 3 connector 5 x 2 wafer, pitch 2.00mm
JCOM4 Serial Port 4 connector 5 x 2 wafer, pitch 2.00mm
JCOM5 Serial Port 5 connector 5 x 2 wafer, pitch 2.00mm
JCOM6 Serial Port 6 connector 5 x 2 wafer, pitch 2.00mm
JDIO General purpose I/O connector 10 x 2 wafer, pitch 2.00mm
JLED1 LED indicator connector 5 x 2 wafer, pitch 2.00mm
LED1 HDD/Power LED indicator
JLVDS1 LVDS Connector DIN 40-pin wafer, pitch 1.25mm
JTOUCH1 Touch panel connector 5 x 1 header, pitch 2.54mm
USB01 USB connector 1 & 2
JUSB23 USB connector 3 & 4 5 x 2 wafer, pitch 2.00mm
JUSB45 USB connector 5 & 6 5 x 2 wafer, pitch 2.00mm
LAN1 RJ-45 Ethernet 1
LAN2 RJ-45 Ethernet 2
KB_MS1 PS/2 keyboard & mouse connector
JKBMS1 PS/2 keyboard & mouse connector 3 x 2 header, pitch 2.00 mm
BT1 Battery connector 2 x 1 wafer, pitch 1.25mm
JAMP_R AMPLIFIER_R 2 x 1 wafer, pitch 2.00mm
JAMP_L AMPLIFIER_L 2 x 1 wafer, pitch 2.00mm
MPCIE1 Mini-PCI connector 1
Supports mSATA (w/o USB
signals)
MPCIE2 Mini-PCI connector 2
Supports WiFi/3G w/ SIM
(Standard MPCIe w/ USB
signals)
JLPC1 LPC connector 5 x 2 header, pitch 2.00mm
PWR1 Power connector 2 x 2 wafer, pitch 4.20mm
PWR2 Power connector
RSTBTN Reset button
JSPI1 SPI connector 4 x 2 header, pitch 2.00mm
JEC_ROM1 EC Debug connector 3 x 1 header, pitch 2.00 mm
SPWR1 SATA Power connector 2 x 1 wafer, pitch 2.00mm
CF1 Compact Flash card connector SATA1 & CF are not co-working
