User’s Manual
EBM-BYT User’s Manual 11
1.5 System Specifications
System
CPU Onboard Intel Bay Trail-M/D/I SoC
BIOS AMI uEFI BIOS, 64/128Mbit SPI Flash ROM
System Chipset Valleyview SoC Integrated
I/O Chip EC (IT8528E)
System Memory
One 204-pin DDR3 SODIMM Socket, Supports Up to
8GB DDR3L 1333MHz SDRAM
SSD One CompactFlash Type I/II Socket (Supports CF-SATA)
Watchdog
Timer
H/W Reset, 1sec. ~ 65535sec. and 1sec step
H/W Status
Monitor
Monitoring System Temperature, Voltage, and Cooling
Fan Status with Auto Throttling Control
Expansion
1 x mPCIe with SIM Slot
1 x mPCIe Supports mSATA
I/O
MIO
1 x SATA II
2 x Mini PCIe, 1 x SIM
2 x RS-232/422/485 (COM1 selected by BIOS, COM2 selected by switch)
4 x RS-232 (option)
1 x CF-SATA/CF
1 x Mic/Line-in/Line-out
2 x LAN (1 x optional K/B & Mouse)
USB 1 USB 3.0, 5 USB 2.0
DIO 16-bit General Purpose I/O for DI and DO
Display
Chipset Valleyview SoC Integrated Graphics
Resolution
DP, eDP (2560 x 1600 @ 60 24bpp)
HDMI 1.4a (1920 x 1200 @ 60 24bpp)
Multiple Display HDMI + LVDS
HDMI HDMI 1.4a
LCD
Interface
LVDS
Touch Screen
Interface
Chipset EETI support 5-wire resistive touch
Touch Interface USB
Audio
