EPI-QM67
70 EPI-QM67 User ’s Manual
Item Option Description
PCH LAN Controller
[Disabled]
[Enabled]
Enable or disable onboard NIC
Wake on LAN
Enable or disable integrated LAN
to wake the system
Board Capability
SUS_PWR_DN_ACK
DeepSx
Board Capability –
SUS_PWR_DN_ACK  Send
Disabled to PCH.
DeepSx  Show DeepSx Policies
Azalia
[Disabled]
[Enabled]
[Auto]
Control Detection of the Azalia
device.
Disabled=Azalia will be
unconditionally disabled
Enabled=Azalia will be
unconditionally Enabled
Auto= Azalia will be enabled if
present, disabled otherwise.
Azalia Internal HDMI Codec
[Disabled]
[Enabled]
Enable or Disable internal HDMI
codec for Azalia.
Display Logic
Enable or Disable the PCH
Display logic.
CLKRUN# Logic
Enable the CLKRUN# logic to
stop the PCI clocks.
SB CRID
Enable or Disable SB Compatible
Revision ID.
SMI Lock Enable or Disable SMI lockdown
BIOS Lock
Enable or Disable BIOS Interface
lockdown.
GPIO Lock
Enable or Disable GPIO
lockdown.
High Precision Timer
Enable or Disable High Precision
Event Timer
SLP_S4 Assertion Width
1-2 seconds
2-3 seconds
3-4 seconds
4-5 seconds
Select a minimum assertion width
of the SLP_S4# signal
Set NAND Management
Override
[Disabled]
[Enabled]
Option to override NAND
Management to allow driver or 3
rd
parties software to configure the
NAND module after POST.
