EPI-QM67
64 EPI-QM67 User
’s Manual
Panel Scaling
[Auto]
[Off]
[Force Scaling]
Select the LCD panel scaling
option used by the Internal
Graphics Device.
BIA
[Auto]
[Disabled]
[Level 1] [Level 2] [Level 3]
[Level 4] [Level 5]
Auto: GMCH use VBT Default
Level n: Enabled with selected
Aggressiveness level.
Spread Spectrum clock Chip
[Off]
[Hardware]
[Software]
Hardware: Spectrum is
controlled by Chip.
Software: Spectrum is controlled
by BIOS.
ALS Support
[Disabled] [Enabled]
Valid only for ACPI.
Active LFP
[No LVDS]
[Int-LVDS]
Select the active LFP
configuration.
No LVDS: VBIOS does not enable
LVDS.
Int-LVDS: VBIOS enables LVDS
driver by Integrated encoder.
SDVO LVDS: VBIOS enables
LVDS driver by SDVO encoder.
eDP Port A:LFP Driven by
Int-DisplayPort encoder from
Port-A.
eDP Port-D: LFP Driven by
Int-DisplayPort encoder from
Port-D (through PCH).
Panel Color Depth
[18 Bit]
[24 Bit]
Select the LFP panel color depth
LVDS back light mode
PWM
DC
Select LVDS back light mode
LVDS DC/PWM
00%
25%
50%
75%
100%
Select LVDS backlight DC/PWM
duty
