User ’s Manual
EPI-QM67 User ’s Manual 59
3.6.2.16 Intel ICC
This Integrated Clock Control option.
Item Option Description
Use Watchdog Timer for ICC
[Disable]
Disabled
Enabled
Enable Watchdog Timer
operation for ICC. If enabled,
watchdog Timer will be started
after ICC-related changes. This
timer detects platform instability
caused by wrong clock settings.
Turn off unused PCI/PCIe
clocks [Enable]
Disabled: all clocks turned on:
clocks for empty PCI/PCIe slots
will be turned off to save power.
Platform must be powered off for
changes to take effect.
Lock ICC registers[Static only] All registers
Static only
All registers: all ICC registers will
be locked.
Static only: only static ICC
registers will be locked
3.6.2.17 Sandybridge PPM Configuration
