User ’s Manual
EPI-QM67 User ’s Manual 55
3.6.2.13.1 Serial Port 0 Configuration
Item Option Description
Serial Port
Enabled,
Disabled
Use the Serial port option to
enable or disable the serial port.
Device Settings
IO=3F8h; IRQ=4, Enable or Disable Serial Port
(COM)
Change Settings
Auto
IO=3F8h; IRQ=4,
IO=3F8h; IRQ=3,4,5,6,7,10,11,12
IO=2F8h; IRQ=3,4,5,6,7,10,11,12
IO=3E8h; IRQ=3,4,5,6,7,10,11,12
IO=2E8h; IRQ=3,4,5,6,7,10,11,12
Select an optimal setting for super
IO Device.
UART 232 422 485
UART 232,
UART 422,
UART485
Change the Serial Port as RS232/
422/ 485
