EPI-QM67
66 EPI-QM67 User ’s Manual
3.6.3.1.3 Memory Configuration
Displays system memory information
Item Option Description
DIMM profile
[Default DIMM profile]
[XMP profile 1]
[XMP profile 2]
Select DIMM timing profile that
should be used.
Memory Frequency
[Auto]
[1067] [1333] [1600] [1867] [2133]
Select Memory Frequency in Mhz.
ECC Support
[Disabled]
[Enabled]
Enable or Disable DDR Ecc
Support
Max TOLUD
[Dynamic]
[1 GB] [1.25 GB][1.5 GB]
[1.75 GB] [2 GB] [2.25 GB]
[2.5 GB] [2.75 GB] [3 GB]
Maximum Value of TOLUD.
Dynamic assignment would adjust
TOLUD automatically based on
largest MMIO length of installed
graphic controller.
NMode Support
[Auto]
[1N Mode]
[2N Mode]
NMode support Option.
Memory Scrambler
[Disabled]
[Enabled]
Enable or Disable Memory
Scrambler support.
RMT Crosser Support
Enable or Disable RMT Crosser
Support.
