Free running panel data.
LP Active Period
Free running
Active only
Latch Pulse is the line pulse or latch
pulse for the flat panel data.
LVDS Format 18 Bits, 24 Bits
This item allow to select the LVDS
format.
LVDS_ON to LVDS Data (T1)
Min = 0
Max =1023
LVDS Data to Enbkl_ON (T2)
Min = 0
Max =511
This items allow to change the LVDS
panel power on timing. Unit: ms
Enbkl_OFF to DATA_OFF (T3)
Min = 0
Max =511
Data_OFF to LVDS_OFF (T4)
Min = 0
Max =1023
This items allow to change the LVDS
panel power off timing. Unit: ms
3.5.3.7 Onboard Audio
This item allows you to enable the onboard audio function.
The choices: Enabled, Disabled.
3.5.3.8 Memory Hole At 15M-16M
This item allows you to reserve the memory area for some specific ISA card’s use.
The choices: Enabled, Disabled.
3.5.4 Integrated Peripherals
Use this menu to specify your settings for integrated peripherals.
Item Options Description
On-Chip IDE Channel 1
Enabled
Disabled
This item allows to enable On-chip IDE channel.
Master Drive PIO Mode
Slave Drive PIO Mode
Auto
Mode 0
Mode 1
Mode 2
Mode 3
The IDE PIO (Programmed Input/Output) fields
let you set a PIO mode (0-4) for each of the four
IDE devices that the onboard IDE interface
supports. Modes 0 through 4 provide
successively increased performance. In Auto
