2.4.6

Primary IDE Connector (IDE)

Signal

PIN

PIN

Signal

RESET#

1

2

GND

PDD7 3 4 PDD8

PDD6

5

6

PDD9

PDD5 7 8

PDD10

PDD4

9

10

PDD11

PDD3 11

12

PDD12

PDD2

13

14

PDD13

PDD1 15

16

PDD14

PDD0

17

18

PDD15

GND 19

20 NC

PDREQ

21

22

GND

PDIOW# 23 24 GND

PDIOR#

25

26

GND

PIORDY 27 28 GND

PDDACK#

29

30

GND

IRQ14 31

32 NC

PDA1

33

34

NC

PDA0 35

36 PDA2

PDCS1#

37

38

PDCS3#

IDEACTP#

39 40 GND

+5V

41

42

+5V

GND 43

44 NC
