User’s Manual
ECM-LX800 User’s Manual 13
1.5 System Specifications
System
CPU
Onboard AMD Geode LX800 @ 0.9 W 500 MHz
Note: Available in different CPU speeds by request
BIOS Award 512 KB Flash BIOS
System Chipset AMD Geode LX 800/CS5536
I/O Chip Winbond W83627HG-AW
System Memory One 200-pin SODIMM socket supports up to 1GB DDR 333/400 SDRAM
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Expansion One PC/104 connector
I/O
MIO
1 x EIDE (Ultra DMA 100), 2 x SATA, 1 x LPT, 3 x RS-232, 1 x
RS-232/422/485, 1 x K/B & Mouse
IrDA 115k bps, IrDA 1.0 compliant
USB 4 x USB 2.0 ports
DIO 16-bit General Purpose I/O for DI and DO
Display
Chipset AMD Geode LX800 with integrated graphics engine
Display Memory 8/16/32/64/128/254 MB frame buffer using system memory
Resolution
CRT mode: 1920 x 1440 @ 32 bpp (85 Hz)
LCD/Simultaneous mode: 1600 x 1200 @ 16 bpp (60 Hz)
LVDS Single channel 18/24-bit LVDS
Audio
Chipset AMD Geode CS5536
AC97 Codec Realtek ALC203 supports 2 CH Audio
Audio Interface Mic in, Line in, CD Audio in, Line out
Ethernet
LAN 1 & 2 Dual Realtek RTL8101L
Ethernet Interface 100Base-Tx Fast Ethernet compatible
