3.1.4 Ethernet
Use this menu to configure internal Ethernet configuration check the printer’s
Ethernet module status, and reset the Ethernet module. This function is available on
the LCD display when Ethernet card is installed.
Press and buttons to select the different options and press
button to enter the option. Press key to cancel the setting and return to the
previous menu.
Exit
Ethernet
Status Configure
¡ х ¡ х
IP Address DHCP
¡ х ¡ х
MAC Static IP
¡ х ¡ х
Exit Exit
Note:
This function is available for M7 PLUS series only and option for M7.
3.1.4.1 Status: (IP Address / MAC)
Use this menu to check the Ethernet setting status.
3.1.4.1.1 IP Address
Ethernet 1/3
> Status
Configure
Exit
The IP address information will be shown on the LCD display. Please press
or button to return to the previous menu.
IP Address
0.0.0.0
Subnet Mask
0.0.0.0
Gateway
0.0.0.0
Status 1/3
> IP Address
MAC
Exit
