Page 6

ZDP100 Instructions, Release 2.0
090805

HomePro

by ADVANCED CONTROL TECHNOLOGIES, INC.

0677-01

COMMAND_CLASS_SWITCH_MULTILEVEL

Version 1

COMMAND_CLASS_SWITCH_ALL

Version 1

COMMAND_CLASS_PROTECTION

Version 1

COMMAND_CLASS_ASSOCIATION

Version 1

COMMAND_CLASS_POWERLEVEL

Version 1

COMMAND_CLASS_CONFIGURATION

Version 1

COMMAND_CLASS_VERSION

Version 1

COMMAND_CLASS_MANUFACTURER_SPECIFIC

Version 1

COMMAND_CLASS_MARK

Version 1

COMMAND_CLASS_SWITCH_BINARY

Version 1

COMMAND_CLASS_SWITCH_MULTILEVEL Version 1

Manufacturer Specific

The ZDP100 supports the Manufacturer Specific command.
The ZDP100 can return Manufacturer Specific information about itself. Refer to your controller’s instructions on
how to get this information from the ZDP100. The following is the manufacturer specific information for the
ZDP100.

SUC Support

There must be a Static Update Controller in your Z-Wave system for this feature to work. The Static Controller
can act as a gateway in the system, since other nodes always know its position (not moved after addition to the
network. The “always listening” advantage of the Static Controller is that other nodes can transmit information
frames to it whenever needed.
You can assign an “SUC Route” to the ZDP100. Refer to your controller’s instructions on how to do this (if it supports
it). Assigning an SUC Route to the ZDP100 allows it to request an update of the Z-Wave devices that are between
it and the Z-Wave device to which it was trying to transmit. The ZDP100 will only request an update when a
transmission fails.

Software Fuse

The ZDP100 is designed to protect itself against loads that exceed it’s maximum power rating. The application
of a load that exceeds that rating is quickly sensed by the dimmer and it responds by immediately shutting off all
power to that load. If the dimmer doesn’t seem to work, or if it only works momentarily, check to see that the total

Z-Wave Library Type

ZW_LIB_SLAVE_ROUTING

Z-Wave Protocol Version

Z-Wave Protocol Sub Version

Application Version

Application Sub Version

M a nufacturer ID 1

0 x 0 0

M a nufacturer ID 2

0 x 0 1

P roduct Type ID 1

'D ' or 0x44

P roduct Type ID 2

'P ' o r 0 x5 0

P roduct ID 1

'0 ' o r 0 x 3 0

P roduct ID 2

'0 ' o r 0 x 3 0
