1.4 IMX-3000 Layout
1
2
3
4
5 6 7 8
9
10
11
12
14
15
17
16
13
1 Power Key 7 Proximity Sensor 13 Camera and Flash LED
2 LCD Display & Touch Panel 8 Receiver 14 Speaker
3 Function Keys 9 Scan Window 15 Battery Cover
4 Microphone 10 Lanyard Loop 16 Volume Up
5 Power LED 11 Earphone Socket 17 Volume Down
6 Light Sensor 12 USB Port
1.5 Package Contents
The IMX-3000 is shipped with the components listed below. If any of the items are missing or
damaged, retain the shipping carton and packing material and contact the dealer for
inspection. Please obtain authorization before returning any product to ADLINK.
• IMX-3000 Handheld Computer
• Li-ion battery (2600 mAh)
• AC adapter and plugs
• Lanyard
• USB cable
• Quick guide
