ADLINK IMX-3000 - Manual (Page 12)

IMX-3000
12
1.3 Specifications
Physical • Dimensions 140.9 x 72.9 x 27.3mm (L x W x H)
• Weight 177g ± 5g (excluding battery)
Processor • 1.2GHz dual CPU
Memory & Storage • 768MB DDR SDRAM / 4GB eMMC Flash
Display • 3.8” WVGA (480 x 800) TFT-LCD
Buttons • 5 keys, 2 side keys
Expansion Slots • microSD x1, supports microSDHC
• SIM slot x1
• SAM slot x1 (for NFC)
• USB 2.0 OTG
Wireless LAN • IEEE 802.11 b/g/n
Wireless WAN • WCDMA 850/1900/2100; GSM 850/900/1800/1900:
HSDPA: 7.2Mb/s; HSUPA: 5.76 Mb/s
Wireless PAN • Bluetooth V4.0
GPS • GPS & Assisted GPS supported
Data Capture • CCD imager
• 1D laser engine
• 2D imager
• NFC PN544 (13.56MHz)
Built-in Sensors • Light sensor
• G sensor
• E-Compass
• Proximity sensor
Notification • Vibrator, triple LED (R, G, B)
Camera • 5M pixel camera with AF, flash LED (standard)
• 2M pixel CMOS without AF (optional)
Audio • 3.5 mm headset x1
• Receiver x1
• Microphone x1
• Speaker: 90dB 1KHz @ 10cm
Battery • Rechargeable 2600mAh 3.7V Li-ion battery (3900mAh
optional)
Power Adapter • Input AC 100~240 V, 50/60 Hz
• Output: DC 5V, 3.5 A min.
OS • Android 4.0
IMX-3000 Specifications
