ADLINK MXC-4000 Series User Manual
Page 57
BIOS Settings and Driver Installation
47
Third IDE Master
Press < Enter > to configure the first device (master) on IDE
interface.
Third IDE Slave
Press < Enter > to configure the second device (slave) on IDE
interface.
4.1.2.3
SuperIO Configuration
Serial Port1/ Port2/ Port3/ Port4 Address
These four options specify the base I/O port address of serial
port1 to serial port4.
Note:
Do not set the same value for different serial ports to
avoid resource conflict.
COM1 Mode/COM2 Mode
Software configure the COM1 and COM2 port mode, options
are RS232,RS422 and RS485.
4.1.2.4
Hardware Health Configuration
The hardware health option allows users to monitor hardware sta-
tus including CPU temperature, system temperature, and system
voltages (Vcore, +5V, +3.3V, +12V, +1.8V, 5VSB, VBAT).
