System Description 19
Matrix MXC-4000 Series
User’s Manual
Active/Link LED
Speed LED
2.4.1 USB 2.0 connectors
The MXC-4002D/4011D controller provides four USB 2.0 ports in
Type A USB connectors on the front panel. All USB ports are com-
patible with high-speed, full-speed and low-speed USB devices.
The MXC-4000 series supports multiple boot devices, including
USB flash drive, USB external hard drive, USB floppy, USB CD-
ROM and etc. The boot priority and boot device can be configured
in BIOS. Please refer to section 4.1.5 for details.
LED Color Status Description
Yellow
Off Ethernet port is disconnected
ON Ethernet port is connected and no data transmission
Flashing
Ethernet port is connected and is transmitting/receiv-
ing data.
Table 2-4: Active/Link LED
LED Color Status Description
Green/Orange
Off 10 Mbps
Green 100 Mbps
Orange 1000 Mbps
Table 2-5: Speed LED
