PRELIMINARY
Power Supply & Consumption
59
MXC-2300
Appendix A Power Supply & Consump-
tion
A.1 Power Consumption Reference
Power consumption as follows is based on lab data in which 24V
DC is applied and current is measured by the DC power supply.
The power consumption (W) is calculated as the product of
applied voltage (V) and the current (A).
Platforms tested for this data have available external I/O inter-
faces, and are attached to supported devices such as VGA and
DVI monitors, CFast card, PS2 keyboard/mouse, USB dummy
load (5VDC 500mA), external SATA , COM loopback, and audio
loopback, and an internal hard disk driver is installed.
No internal PCI/PCIe/mini PCIe slots are occupied.
Information is presented for reference only. Actual power con-
sumption will vary with different attached devices and platform
operations.
Table A-1: Power Consumption
NOTE:
NOTE:
Information in this Appendix is for power budget planning and
design purposes only. Actual power consumption may differ
based on final application.
Power Supply:
24VDC
Power Off
System Idle
System Full
Load
Recommended
Power Supply
Integrated Embedded Computer
MXC-2300CD
0.1A (2.4W)
0.62A
(14.88W)
1.56A
(37.44W)
90W /100W
