PRELIMINARY
Introduction 3
MXC-2300
1.3 Specifications
MXC-
2300CD-3E1
MXC-
2300CD-3S
MXC-
2300-3E1
MXC-
2300-3S
System Core
Processor
Intel
®
Atom
™
Processor E3845 (Bay Trail-I
Premium)
4C @ 1.91GHz CPU
Chipset Intel SoC (System on Chip)
Video
1 DisplayPort +1 DVI-I (VGA or DVI-D)
DP: resolution up to 2560x1600
VGA: resolution up to 1600x1200
Memory
4GB DDR3L 1333MHz SODIMM module, (up to
8GB with 2 SODIMM sockets)
I/O Interface
Expansion
slots
2 PCI+1
PCIe x4
3 PCI
2 PCI+1
PCIe x4
3 PCI
Ethernet
2 Intel
®
GbE ports (Intel
®
Springville WGI210IT
chipset)
Teaming function, Wake On LAN
Serial Ports
2 software-programmable RS-232/422/485 (COM
1&2) with auto-flow control, 2 RS-232 (COM 3&4)
USB
5 external USB ports (4 USB 2.0 + 1 USB 3.0) + 1
internal USB 2 .0
CAN
2 DB9 isolated CAN port
with SjA1000 CAN
controller
-
DIO
16-CH DI and 16-CH DO
with 1.5KV isolation
-
Mini PCIe
1 internal mini PCIe card
socket
-
USIM
1 USIM socket for 3G
communication
-
Audio 1 MIC-in and 1 Line-out
