PRELIMINARY
Introduction 25
MXC-2300
Figure 1-14: DisplayPort Connector
Table 1-10: DisplayPort Pin Assignments
Table 1-11: Applicable Cable Types
1.6.12 Audio Jacks
The MXC-2300 implements Intel High Definition audio on a
Realtek ALC269 chip. The HD audio supports up to 24-bit, 192
KHz sample rate high quality headphone/line out and microphone
Pin Signal Pin Signal
1 CN_DDPx0+ 11 GND
2 GND 12 CN_DDPx3-
3 CN_DDPx0- 13 CN_DDPx_AUX_SEL
4 CN_DDPx1+ 14 CN_DDPx_CONFIG2
5 GND 15 CN_DDPx_AUX+
6 CN_DDPx1- 16 GND
7 CN_DDPx2+ 17 CN_DDPx_AUX-
8 GND 18 CN_DDPx_HPD
9 CN_DDPx2- 19 GND
10 CN_DDPx3+ 20 +V3.3_DDPx_PWR_CN
P/N Description
30-01119-0000 Passive DisplayPort to HDMI adapter cable
30-01120-0000 Passive DisplayPort to DVI adapter cable
30-01121-0000 Passive DisplayPort to VGA adapter cable
30-01157-0000 Active DisplayPort to DVI adapter cable
