Board Interfaces 33
VPX3000
RP2 Connector
Pin G F E D C B A
1 VGA-VS GND J16-A11 J16-B11 GND J16-D11 J16-E11
2 GND J16-A13 J16-B13 GND J16-D13 J16-E13 GND
3 VGA-R GND J16-A5 J16-B5 GND J16-D5 J16-E5
4 GND J16-A7 J16-B7 GND J16-D7 J16-E7 GND
5 VGA-B GND J16-A9 J16-B9 GND J16-D9 J16-E9
6 GND J16-A15 J16-B15 GND J16-D15 J16-E15 GND
7 VGA-G GND J16-A17 J16-B17 GND J16-D17 J16-E17
8 GND J16-A19 J16-B19 GND J16-D19 J16-E19 GND
