ADLINK VPX3000 User Manual

Page 22

Specifications

Notes:

1. The storage device limits the operational vibration. When appli-

cation requires higher specification for anti-vibration, it is rec-
ommended to use a flash storage device.

XMC

• One PCIe 2.0 x8 conduction cooled XMC.3 site
• Jn6 rear XMC I/O connector compliant to VITA 46.9,

X8d+X12d

Front Panel I/O • Reset button

• Power LED

Storage

Interfaces

• Onboard SATA NAND flash on SATA 3 Gb/s, up to 32GB
• SATA 6 Gb/s port 0 and 1 to P1
• SATA 3 Gb/s port 2 to P2

BIOS

• AMI EFI BIOS, 64Mbit SPI flash memory

P1 Interface

• Line-in
• Line-out
• 2x SATA 6 Gb/s ports
• 2x USB 2.0
• USB 3.0
• 10/100/1000BASE-T Gigabit Ethernet Ports
• 2x 1000BASE-BX SerDes Port

P2 Interface

• VGA
• RS-232
• RS-422
• DVI
• SATA 3 Gb/s port
• XMC X8d+X12d

Environmental

• Operating Temperature:

-40°C to +75°C (for Intel® Core™ i7-3612QE)
-40°C to +85°C (for Intel® Core™ i7-3555LE)

• Storage Temperature: -50°C to 100°C
• Humidity: 95%, non-condensing
• Shock: 40G peak-to-peak, 11ms duration, non-operating
• Vibration

: Operating 5Grms, 20-2000Hz, each axis w/o

hard drive

• Altitude:

EMI

• CE EN55022
• FCC Class A

Table 2-1: VPX3000 Blade Specifications
