32 Board Interfaces
RP1 Connector
Pin G F E D C B A
1 GPIO0 GND NC NC GND NC NC
2 GND NC NC GND NC NC GND
3 GPIO1 GND NC NC GND NC NC
4 GND NC NC GND NC NC GND
5 GPIO2 GND MDIN1 MDIP1 GND MDIN0 MDIP0
6 GND MDIN3 MDIP3 GND MDIN2 MDIP2 GND
7 Maskreset GND NC NC GND NC NC
8 GND NC NC GND NC NC GND
9 GPIO3 GND DVI_TX1- DVI_TX1+ GND DVI_TX0- DVI_TX0+
10 GND DVI_TXC- DVI_TXC+ GND DVI_TX2- DVI_TX2+ GND
11 VGA_SDA GND ? DVI_HPD GND DVI_SCL DVI_SDA
12 GND SIN SOUT GND CTS# RTS# GND
13 VGA_SCL GND RS422_TX- RS422_TX+ GND RS422_RX- RS422_RX+
14 GND Linein-L Linein-R AGND Lineout-L Lineout-R AGND
15 VGA-HS GND J16-A1 J16-B1 GND J16-D1 J16-E1
16 GND J16-A3 J16-B3 GND J16-D3 J16-E3 GND
