Board Interfaces

23

VPX3000

VPX Connectors

P0 Connector

Pin

G

F

E

D

C

B

A

1

+12V

+12V

+12V

None

+3.3V

+3.3V

+3.3V

2

+12V

+12V

+12V

None

+3.3V

+3.3V

+3.3V

3

+5V

+5V

+5V

None

+5V

+5V

+5V

4

I2C_CLK

I2C_DAT

GND

+12V_AUX

GND

SYSRESET

NC

5

GAP

GA4

GND

+3.3V_AUX

GND

SM0_CLK

SM1_DATA

6

GA3

GA2

GND

+12V_AUX

GND

GA1

GA0

7

TCK

GND

TDO

TDI

GND

TMS

TRST

8

GND

REF_CLK- REF_CLK+

GND

NC

NC

GND
