Page 32: Figure 4-2: vpx3000 mechanical drawing

background image

20

Board Interfaces

4.2

VPX3000 Mechanical Drawing

Figure 4-2: VPX3000 Mechanical Drawing

Power LED

LED

Color

Condition

Indication

Power

Green

OFF

System is off

ON

System is on

160

99.85

14.34

4.6

18.94

Power
LED
