24 Board Interfaces
P1 Connector
Pin G F E D C B A
1 NC GND L0-TX- L0-TX+ GND L0-RX- L0-RX+
2 GND L1-TX- L1-TX+ GND L1-RX- L1-RX+ GND
3 VBAT GND L2-TX- L2-TX+ GND L2-RX- L2-RX+
4 GND L3-TX- L3-TX+ GND L3-RX- L3-RX+ GND
5 SYSCON# GND L4-TX- L4-TX+ GND L4-RX- L4-RX+
6 GND L5-TX- L5-TX+ GND L5-RX- L5-RX+ GND
7 NC GND L6-TX- L6-TX+ GND L6-RX- L6-RX+
8 GND L7-TX- L7-TX+ GND L7-RX- L7-RX+ GND
9 GPIO1 GND SATA0-TX- SATA0-TX+ GND SATA0-RX- SATA0-RX+
10 GND SATA1-TX- SATA1-TX+ GND SATA1-RX- SATA1-RX+ GND
11 GPIO6 GND USB3_RX1- USB3_RX1+ GND USB3_TX1- USB3_TX1+
12 GND USB2_0- USB2_0+ GND USB2_6- USB2_6+ GND
13 GPIO7 GND TP01_DB- TP01_DB+ GND TP01_DA- TP01_DA+
14 GND TP01_DD- TP01_DD+ GND TP01_DC- TP01_DC+ GND
15
MASKABLE
_RESET
GND UTP2_TD- UTP2_TD+ GND UTP2_RD- UTP2_RD+
16 GND UTP1_TD- UTP1_TD+ GND UTP1_RD- UTP1_RD+ GND
Lxx: PCI Express x8
SATAxx: SATA
USB3xx: USB 3.0
UTPxx: 1000 BASE-BX
TPxx: 1000 BASE-T
USB2xx: USB 2.0
