12 Specifications
Power Consumption
This section provides information on the power consumption of the
cPCI-6510 Series with different CPUs, 2GB DDR3-800/1066 sol-
dered memory, and 100GB SATA HDD. The system was tested in
Idle Mode and Full Load Mode under Windows XP running Burn-in
Test 6.0. The cPCI-6510 is powered by 5V and 3.3V.
Idle Mode under Windows XP
Table 2-4: Idle Mode Power Consumption
100% CPU Usage under Windows XP
Table 2-5: 100% CPU Usage Power Consumption
CPU Core™ i7 610E Core™ i7 620LE Core™ i7 620UE
Voltage
(V)
Current
(A)
Power
(W)
Current
(A)
Power
(W)
Current
(A)
Power
(W)
+3.3 4.19 13.82 4.12 18.41 3.85 12.71
+5 1.14 5.69 1.07 5.35 1.05 5.25
Total 19.51 23.76 17.96
CPU Core™ i7 610E Core™ i7 620LE Core™ i7 620UE
Voltage
(V)
Current
(A)
Power
(W)
Current
(A)
Power
(W)
Current
(A)
Power
(W)
+3.3 6.09 20.10 5.83 19.25 5.31 17.52
+5 4.44 22.21 3.57 17.83 2.07 10.35
Total 42.31 37.08 27.87
