92
IPMI User Guide
9.5
Communications with IPMC
Operating systems need to use a serial port to communicate with
the IPMC. The resource setting of the serial port must be IO:
0x3E8 and IRQ: 3. The communication setting of the serial port
must be BaudRate: 9600, DataBit: 8, ParityCheck: None, StopBit:
1, and FlowControl: None. In Windows XP, use “COM3” to com-
municate with the IPMC.
9.6
IPMI Sensors List
9.7
Relevant Documents
Sensor
Number
Sensor name
Normal
Reading
Remark
00h
BMC Watchdog
01h
3.3V
3.3 V
02h
5V
5 V
03h
12V
12 V
04h
SYSTEM Temp
25°C
05h
CPU Temp
40°C
06h
BIOS CHANGE
07h
BIOS POST ERROR
Document Title
Revision
Source
Intelligent Platform
Management Interface
Specification v2.0
Document Revision 1.1
February 20, 2002
PICMG 2.9 D1.0
CompactPCI System
Management Specification
January 21, 2000
Intelligent Platform
Management Bus
Communications Protocol
Specification v0.9
Document Revision 0.15
June 24, 1997
Intel Corp.
