background image

Registers •29

3.6

Digital Output Register

This register is a general-purpose 8 bits digital output port. These signals
can be used to control external devices.

Address: BASE + 0x18

Attribute: write only

Data Format:

Bit

7

6

5

4

3

2

1

0

Base+0x18

DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0

Table 8. Digital Output Register
