GUIDE TO INSTALLATION
The following can be used as a checklist to verify all of the steps necessary for
complete installation of the C-BOX 200.
1) Read all information in the section "Safety Precautions" at the beginning of this
manual.
2) Correctly position and mount the C-BOX 200 within the reach of the barcode
scanner cable, according to the information in paragraph 2.3.
3) Make all electrical connections according to your application. See par. 2.4.
4) Set all the proper configuration jumpers and switches according to your
application. See all sub-paragraphs under 2.4.
5) Connect the scanner to the C-BOX 200.
6) Switch-on the system.
7) Wait until the Warning Led (WL, red) is switched off.
8) Through the internal 9-pin male connector, (it carries the Scanner Aux. Serial Port
signals), configure the scanner according to your specific application using the
WinHost™ software configuration tool.
9) Perform the 'Get Scanner Configuration' procedure using the internal keys (see
paragraph 2.7.1).
10) Wait until the Warning Led (WL, red) is switched Off.
Now the C-BOX 200 contains the scanner configuration.
The installation is complete.
