Electrical characteristics curves – Delta Electronics Q48SP User Manual
Page 5
DS_Q48SP12017_05302008
5
ELECTRICAL CHARACTERISTICS CURVES
Figure 9:
Test set-up diagram showing measurement points
for Input Terminal Ripple Current and Input Reflected Ripple
Current.
Note: Measured input reflected-ripple current with a
simulated source Inductance (L
TEST
) of 12 μH. Capacitor Cs
offset possible battery impedance. Measure current as
shown above.
Figure
10:
Input reflected ripple current, i
c
through a 12µH
source inductor at nominal input voltage and rated load current
(20 mA/div).
