PART NUMBERING SYSTEM
Q 48 S P 120 17 N R F A
Form
Factor
Input
Voltage
Number of
Outputs
Product
Series
Output
Voltage
Output
Current
ON/OFF
Logic
Pin
Length
Option Code
Q - Quarter
Brick
48 -
36~75V
S - Single P - 200W
series
120 - 12V 18A N - Negative
P - Positive
E - Negative and
no trim, no sense
pins R - 0.170”
N - 0.145”
K - 0.110” F- RoHS 6/6
(Lead Free)
Space - RoHs
5/6
A - Std. Function
with case pin
B - w/o case pin
H - With
heatspreader and
case pin
MODEL LIST
MODEL NAME INPUT OUTPUT EFF @ 100% LOAD
Q48SP12017NRFA 36V~75V 7A 12V 18A 92.5%
Q48SP12017NRFH 36V~75V 7A 12V 18A 92.5%
Q48SP12017ERFB 36V~75V 7A 12V 18A 92.5%
Q48SP12017ERFH 36V~75V 7A 12V 18A 92.5%
