FEATURES
Š High efficiency: 92.5 % @12V/18A
Š Size: 57.9x36.8x10.8mm (2.28”x1.45”x0.43”)
(w/o heatspreader)
57.9x36.8x12.7mm (2.28”x1.45”x0.50”)
(with heatspreader)
Š Industry standard pin out
Š Fixed frequency operation
Š Fully protected: OTP, OVP, OCP, UVLO
Š No minimum load required
Š Wide output trim range: -20~+10%
Š Remote sense
Š Fast transient response
Š Basic insulation and 2250V isolation
Š ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing facility
Š UL/cUL 60950-1 (US & Canada) recognized,
TUV (EN60950-1) certified
Š CE mark meets 73/23/EEC and 93/68/EEC
directives
OPTIONS
Š Latched over current protection
Š Positive remote on/off
Š Short lead lengths
APPLICATIONS
Š Telecom/DataCom
Š Wireless Networks
Š Optical Network Equipment
Š Server and Data Storage
Š Industrial/Test Equipment
Delphi Series Q48SP, 216W Quarter Brick Family
DC/DC Power Modules: 48V in, 12V/18A out
The Delphi Series Q48SP Quarter Brick, 48V input, 12V single output,
isolated, DC/DC converters are the latest offering from a world leader in
power systems technology and manufacturing ― Delta Electronics, Inc.
This product family provides up to 216 watts of power or up to 18A of
output current in an industry standard footprint. With creative design
technology and optimization of component placement, these converters
possess outstanding electrical and thermal performance, as well as
extremely high reliability under highly stressful operating conditions.
All
models are fully protected from abnormal input/output voltage, current,
and temperature conditions. The Q48SP Delphi Series converters meet all
safety requirements with basic insulation.
DATASHEET
DS_Q48SP12017_05302008
