Recommended interface circuit (ac coupling) – Delta Electronics SFBD-1250B4Q1R User Manual
Page 5
SFBD-1250B4Q1R
DELTA ELECTRONICS, INC.
5 Revision:
S0
04/12/2007
www.deltaww.com
7. Recommended Interface Circuit (AC Coupling)
Transmitter
100ohm
100nF
100nF
9. TD(p)
10. TD(n)
8. Tx_Dis
6. VccT
7. VeeT
Receiver
100nF
100nF
1. VeeR
5. RD(p)
4. RD(n)
3. SD
2. VccR
100nF
10uF
100nF
10uF
100nF
1uH
1uH
3.3V
Protocol IC
SerDes IC
100ohm
Tx_Dis
SD
DELTA SFF Module
Z0=50ohm
Z0=50ohm
Z0=50ohm
Z0=50ohm
150ohm
150ohm
RES
* RES is the internal 4.7K to 10K Ohms pull-up resistor.
VccR
