30 © 2003 directed electronics, inc.
Feature steps 5 and 6 are related. If Auxiliary Output Enabled is selected in feature 5
then either Auxiliary Output or Delayed Accessory Output can be selected in feature
step 6. Examples of this are where Auxiliary Output is used to provide a momentary
800msec pulse on the RED/WHITE wire of the main harness (can be used for open-
ing the trunk). The delayed accessory output is used to allow selected vehicle acces-
sories to remain on (such as radio) when the ignition is turned off. This output will
remain active for 1 hour, or until a door is opened and closed, or when a button on
the factory remote transmitter is pressed.
features #2 menu
Default settings are shown in bold.
N NO OTTEE:: Feature step number 6 and 7 are not applicable to the 427A.
Feature
Step
Lock Button (one chirp) Unlock Button (two chirps)
1 Ignition-Controlled Locking ON Ignition-Controlled Locking OFF
2 Ignition-Controlled UnLocking ON Ignition-Controlled Unlocking OFF
3 Active Locking Passive Locking
4 Door Lock Pulse Duration–0.8 sec. Door Lock Pulse Duration–3.5 sec.
5 Single Unlock Pulse Double Unlock Pulse
6 Channel 3: Validity Channel 3: Second Unlock
7 Code Hopping ON Code Hopping OFF
