© 2003 directed electronics, inc.
15
used to control optional accessories. If programmed for delayed accessory output, this
wire will provide (-) ground when the ignition is turned off and will continue to output
(-) ground until a door is opened then closed. This can be used to energize the acces-
sory circuit in the vehicle to keep the radio and other accessories on after the ignition
is turned off.
IIM MPPO ORRTTA AN NTT!! Never use this wire to drive anything but a relay or a low-current input!
This transistorized output can only supply (-) 200 mA, and connecting directly to a sole-
noid, motor, or other high-current device will cause the module to fail.
N NO OTTEE:: Zones 2 and 4 are shunted when this channel becomes active. Zones 2 and
4 reactivate 5-seconds after this channel’s output ceases.
auxiliary harness wire connection guide
auxiliary harness wiring diagram
___
___
___
___
___
___
___
YELLOW/BLACK Light Flash Monitor Input
VIOLET/BLACK No Function
GRAY (+) Trunk Release/Sensor Shunt Input
BLUE Disarm Input
RED Disarm Defeat Input
GREEN Arm Input
BROWN (-) Horn Honk Output H2/1
H2/2
H2/3
H2/4
H2/5
H2/6
H2/7
