internal programming jumper
A 10A fuse is used as both a fuse and a program jumper. This jumper determines the
light flash output polarity. In the (+) position, the on-board relay is enabled and the
unit will output (+)12V on the WHITE wire, H1/2. In the (-) position, the on-board
relay is enabled for (-) output on the WHITE wire, H1/2. To access the jumper, remove
the sliding door from on top of the control module, as shown below.
FUSE/JUMPER
(-) POSITION
FUSE/JUMPER
(+) POSITION
