OPT-155Bxxxxxx
DELTA ELECTRONICS, INC.
http://www.deltaww.com
2
Jan., 2008
Rev.：0H
Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Lead Soldering Temperature T
SOLD
260 ºC
Lead Soldering Time t
SOLD
10 Sec.
Supply Voltage V
CC
0 6 V
Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Data Rate 100 155.52 200 Mbps
Ambient Operating Temperature T A 0 70 ºC 1
Supply Voltage
OPT-155B1xxxxx
OPT-155B2xxxxx V CC 4.75
3.15 5
3.3
5.25
3.45 V
Note: See “Order Information” for detail
Electrical Characteristics
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Transmitter Data Input Voltage-Low V IL -V CC -1.81 -1.48 V
Transmitter Data Input Voltage-High V IH -V CC -1.16 -0.88 V
Receiver
Data Output Voltage-Low V OL -V CC -1.95 -1.62 V
Data Output Voltage-High V OH -V CC -1.045 -0.74 V
SD Output Voltage-Low V
SDL
-V CC -1.95 -1.62 V
SD Output Voltage-High V
SDH
-V CC -1.045 -0.74 V
Optical Characteristics
（Data Rate = 155.52Mbps, PRBS=2 23
-1, NRZ, 9/125um SMF）
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Supply Current Icc 165 mA
-20 -15 OPT-155BxHxxxx
-15 -8 OPT-155BxJxxxx
-8 -5 OPT-155BxLxxxx
Mean Launch Power P
O
-5 0
dBm
OPT-155BxMxxxx
8.2 OPT-155BxHxxxx
8.2 OPT-155BxJxxxx
8.2 OPT-155BxLxxxx
Optical Extinction Ratio E.R.
10
dB
OPT-155BxMxxxx
Center Wavelength λ
C
1270 1310 1360 nm
7.7 OPT-155BxHxxxx
7.7 OPT-155BxJxxxx
7.7 OPT-155BxLxxxx
Spectral Width (RMS) σ
3
nm
OPT-155BxMxxxx
Output Eye Diagram Compliant with ITU-T recommendation G.957
Receiver
Supply Current Icc 145 mA
-31 OPT-155BxHxxxx
-31 OPT-155BxJxxxx
-31 OPT-155BxLxxxx
Sensitivity P
IN
-34
dBm
OPT-155BxMxxxx
Overload P
SAT
-8 dBm
Signal Detect-Asserted P
A
-31 dBm OPT-155BxHxxxx
