OTHER CONNECTIO

CONNECTING OPTIONAL
EQUIPMENT

LISTENING TO EXTERNAL

SOURCES

Refer to the operating instructions of the connected equipment

for details.

• The connecting cords are not supplied. Obtain the necessary

connecting cords.

• Consult your local Aiwa dealer for optional equipment.

AUX Jacks

This unit can input analog sound signals through these jacks.

Use a cable with RCA phono plugs to connect audio equipment
(turntables, LD players, VCRs, etc.).

Connect the red plug to the R jack, and the white plug to the L

jack.

When connecting a turntable

Use an Aiwa turntable equipped with a built-in equalizer amplifier.

To play equipment connected to the AUX jacks, proceed as
follows.

1 Press the AUX button.

"AUX" appears on the display.

2 Play the connected equipment.

DC JACK (12V)

Connect the Aiwa DCW-50 car battery cord to the jack. Then
connect the other end to the cigarette lighter socket of the car.

ENGLISH
