SPEAKER SYSTEM SX-NMT10Q0
STEREO RECEIVER MX-NM1000
FM tuner section
Tuning range 87.5 MHz to 108 MHz
Usable sensitivity (IHF) 13.2 dBf
Antenna terrninals 75 ohms (unbalanced)
AM tuner section
Tuning range 530 kHz to 1710 kHz (10 kHz step)
Usable sensitivity
531 kHz to 1602 kHz (9 kHz step)
350 pV/m
Antenna Loop antenna
Amplifier section
Power output 65 W + 65 W (50 Hz - 20 kHz, THD
Total harmonic distortion
less than 1%, 6 ohms)
0.1 % (8 W, 1 kHz, 6 ohms, DIN
Inputs
AUDIO)
VIDEO/AUX: 150 mV (adjustable)
Outputs
MD: 150 mV (adjustable)
MIC 1, MIC 2: 1 mV (10 kohms)
LINE OUT: 210 mV
General
SPEAKERS: accept speakers of 6
ohms or more
SURROUND SPEAKERS:
accept speakers of 8 ohms to 16
ohms
PHONES (stereo jack): accepts
headphones of 32 ohms or more
Power requirements 120 V AC, 60 Hz
Power consumption 105 W
Dimensions of main unit 260 X 121.5 X 345 mm
(W
X
H
X
D) (IOV 4 X 478 X 137s in.)
Weight of main unit 5.8 kg (12 lbs 14 oz.)
CASSETTE DECK FX-NM1000
Track format 4 tracks, 2 channels stereo
Frequency response Type II (high/CrOz) tape:
Signal-to-noise ratio
50 Hz - 16000 Hz
Type I (normal) tape:
50 Hz - 15000 Hz
60 dB (Dolby B NR ON, Type II
Recording system
tape peak level)
AC bias
Heads Deck 1 : Playback head x 1
Dimensions of main unit
Deck 2:Recording/piayback head
X
1, erase head
x
1
260
X
121.5
X
318 mm
(W
X
H
X
D) (IOV 4 X
47 b X
12Vs in.)
Weight of main unit 1.8 kg (3 lbs 15 oz.)
CD PLAYER DX-NM1000
Laser Semiconductor laser (X = 780 nm)
D-A converter 1 bit dual
Signal-to-noise ratio 85 dB (1 kHz, 0 dB)
Harmonic distortion 0.05 % (1 kHz, 0 dB)
Wow and flutter Unmeasurable
Dimensions of main unit 260 X 106 X 318 mm
(W X H X D) (10V4X4V4X 1278ln.)
Weight of main unit 2.2 kg (4 lbs 14 oz.)
GRAPHIC EQUALIZER GE-NM1000
Dimensions of main unit 260 X 100.5 X 322 mm
(W
X
H
X
D) (IOV 4 X 4 X 1274 in.)
Weight of main unit 1.0 kg (2 lbs 3 oz.)
Cabinet type
Speakers
Impedance
Output sound pressure level
Dimensions (W x H x D)
Weight
3 way (magnetic shielded type)
Woofer:
140 mm (5% in.) cone type
x
2
Tweeter:
60 (2 % in.) mm cone type
Super tweeter:
20 mm (i=^/i6 in.) ceramic type
6 ohms
88 dB/W/m
220
X 440 X 250 mm
(8 % X 17 % X OVs in.)
5.8 kg (12 lbs 14 oz.)
Specifications and external appearance are subject to change without
notice.
UISE SYSTEM
The word “BBE” and the “BBE symbol” are trademarks of BBE
Sound, Inc.
Under license from BBE Sound, Inc.
DOLBY NR
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
“DOLBY” and the double-D symbol □□ are trademarks of Dolby
Laboratories Licensing Corporation.
COPYRIGHT
Please check the laws on copyright relating to recordings from
discs, radio or external tape for the country in which the machine
is being used.
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digifal device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference fo radio
communicafions. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radlo/TV technician
for help.
CAUTION
Modifications or adjustments to this product, which are not
expressiy approved by the manufacturer, may void the user’s
right or authority to operate this product.
<
a
111
z
111
o
ENGLISH
33
