SPBD-155E4J1RT
DELTA ELECTRONICS, INC.
2 Revision: S1
09/20/2006
www.deltaww.com
1. Absolute Maximum Ratings
Parameter Symbol Min. Typ. Max. Unit Note
Storage Temperature Ts -40 85 ºC
Storage Ambient Humidity H A 5 95 %
Power Supply Voltage V CC 0 5 V
Signal Input Voltage -0.3 Vcc+0.3 V
Optical Input Power (Peak) 4 dBm
2. Recommended Operating Conditions
Parameter Symbol Min. Typ. Max. Unit Note
Operating Case Temperature T C -40 85 ºC Note (1)
Ambient Humidity H A 5 85 % Non-condensing
Power Supply Voltage V CC 3.135 3.3 3.465 V
Power Supply Current I CC 250 mA
Power Supply Noise Rejection 100 mVp-p 100Hz to 1MHz
Data Rate 10 155.52 Mbps
Transmission Distance 15 km
Note (1). Measured on topside of case front center.
3. Specification of Transmitter
Parameter Symbol Min. Typ. Max. Unit Note
Average Launched Power P
O
-14 -8 dBm Note (1)
Optical Extinction Ratio ER 10 dB
Center Wavelength λ
C
1260 1310 1360 nm FP Laser
Spectrum Width (RMS) σ 6 nm
Transmitter OFF Output Power P
Off
-45 dBm
Optical Rise/Fall Time t
r
/t
f
1.3 ns Note (2)
Total Jitter TJ 1 ns Note (3)
Optical Return Loss Tolerance ORLT 14 dB
Relative Intensity Noise RIN -116 dB/Hz
Dispersion Penalty TDP 1 dB
Output Eye Mask
Compliant with Bellcore TR-NWT-000253
and ITU recommendation G.957
Note (4)
Note (1). Launched power (avg.) is power coupled into a single mode fiber.
Note (2). These are unfiltered 20-80% values.
Note (3). Measure at 2
23 -1 NRZ PRBS pattern.
Note (4). Eye Mask definition
