WALL MOUNTING INSTALLATION )
Room station:
Attach the mounting bracket with screws to wall or gang
box. Insert the prongs of the bracket into the holes of the
body and pull the body downward.
(Be careful not to attach the bracket upside down).
Door station:
* Attach bottom case to wall or gang box. Connect wires
and insert front panel.
C ADJUSTING VOLUME CONTROL^
The incoming call tone volume may be adjusted to three levels by
setting switch as desired.
HANCi
F R O N T , T E R M I N A L S
P A N E L ' B R A C K E T
I / ^^^
3
® —
S C R E W ; W I R I N G
F O R ; C A B L E
P A N E L M O U N T I N G
S C R E W ( x 2 )
TC-MF MASTER
m iiQ: ffl] r; m
S E T T O : L E F T M I D D L E
LED FOR BATTERY CHECK
The system is designed for low current consumption providing longer battery life. Battery check LED is mounted on
the TC-MF master.
TC-MF MASTER
CONDITION #1 CONDITION #2
Lights normal during
conversation.
* Becomes dark during
conversation.
CONDITION #3
1
* Does not light during
conversation.
- - vAdv-
Tj 1 0
Batteries are powerful
enough to function the
system.
Batteries get weaker but
don’t have to be
replaced yet.
Batteries are exhausted
and must be replaced by
new ones.
BEFORE YOU INSTALL AND OPERATE THE EQUIPMENT - Prohibitions and precautions-
Operation;
1. DO NOT HOLD HOOK SWITCH DOWN WHILE PICKING UP HANDSET. THE CALL
TONE SOUNDS THRU THE HANDSET RECEIVER ELEMENT AND COULD CAUSE
HEARING DAMAGE.
Installation;
1. DO NOT CONNECT ANY TERMINAL ON ANY UNIT TO AC POWER LINES.
2. Be sure to remove plug of power supply from AC outlet before you open the unit or make
wiring connections.
3. Avoid running the connecting wires thru doors, windows or between furniture, which may
pinch and disconnectect the wires.
4. The intercom equipment must be installed in as dry and dust-free environment as possible.
Maintenance;
1. Clean your intercom equipment with a soft cloth dampened with neutral household cleanser.
Never use thinner nor benzine, etc.
2. Do not splash water on the door station by hose, etc.
NEVER
NEVER
We at AIPHONE are proud of our products. Our designers and engineers strive to bring you the finest in commu­
nication equipment. Each item has been carefully tested and inspected before leaving our factory. Properly installed and
used, your Aiphone intercom system should give years of trouble-free service.
WARRANTY
'Xiphone uarrants its products to be free from detects ot material and workmanship unift'r normal
use and sersice tor a period of one sear after delivers to the ultimate user and will repair tree oi
charge or replace at no charge, should it become defective upon which examination shall disclose
to be defective and under vxarrantv. Aiphone reserves unto itself the sole right to make the final
decision whether there is a detect in materials and or workmanship; and whether or not the prod­
uct is within the warrants.
This warrants shall not apply to any Aiphone product which has been subject to misuse, neglect,
accident, or to use in violation of instructions furnished, nor extended to units which have been
repaired or altered outside ot the factors'.
This warrants’ does not cover batteries or damage caused bv batteries used m connection with the
product.
Thi-, warrants covers bench repairs onlv, and any repairs must be made at the shop or place des­
ignated in vsnling bv Aiphone. Aiphone w'lM not be responsible for anv costs incurred involving on
site service calls.
t I t I g I W I iMgllllltrt
Aiphone Co., Ltd., Nagoya, Japan
Aiphone Corporation, Bellevue, Washington
TC-MB-l-0986 ©
